There is a special kind of satisfaction that comes from using the tiny factory tool kit that lives on the side of your bike.
It feels like opening a secret compartment in a spy movie.
Inside: a spark plug wrench that looks like it was designed for someone with very patient hands and a strong belief in destiny.
You loosen the right spark plug. It is extremely tight. So tight you briefly question your life decisions. The left one? Tight, yes. But not “did the factory weld this in?” tight.
And now you are standing there holding two slightly sooty trophies, wondering what comes next.
Let’s talk about it.
How Do I Know I’m Buying the Right Replacements?
The easiest way? Bring the old plugs to the shop. That is perfectly fine.
But even better: know your spec. Check your manual for the correct plugs. ChatGPT kept telling me the wrong plugs. Gemini and Grok nailed it.
Your 2005 Suzuki VS800 Boulevard S50 uses NGK DPR8EA-9 or DENSO X24EPR-U9 spark plugs.
A direct example of the correct plug is the NGK DPR8EA-9, like this one: https://www.ngk.com/ngk-4929-dpr8ea-9-nickel-spark-plug
When buying replacements, check:
- Thread size and reach (must match exactly)
- Heat range
- Electrode style (standard copper is fine unless you are modifying things)
Do not improvise spark plugs. This is not a “close enough” situation.
Do I Need to Buy Anything Else?
Usually, no.
New spark plugs come with a crush washer already installed. That washer is important. More on that in a second.
Optional but helpful:
- A tiny bit of dielectric grease for the plug caps
- A torque wrench (if you want to feel like a professional)
That’s about it.
No incense required.
What About Those Washers?
The washers you saw are crush washers.
They are not decorative. They are not optional. They are not adjustable accessories.
On your old plugs, the washers may have been sitting slightly differently because they were already crushed from previous installation.
New plugs come with a fresh crush washer pre-installed at the correct position. You do not move it. You do not transfer the old washer. You do not stack washers like pancakes.
Just use the new plug as it comes.
How Tight Do They Need to Be?
This is where many people go wrong.
Spark plugs are not lug nuts.
If you have a torque wrench, NGK DPR8EA-9 plugs typically torque to 17.5 N·m (1.8 kg-m, 13.0 lb-ft).
If you do not have a torque wrench:
- Thread it in by hand first. Always.
- Make sure it turns smoothly. If it does not, stop immediately.
- Once it seats, tighten about 1/2 turn more to crush the washer.
Do not muscle it like the previous owner apparently did on your right cylinder.
Aluminum threads are forgiving once. Only once.
Any Trick to Reconnecting the Leads?
Yes.
Before reinstalling the plug caps:
- Check the rubber boots for cracks.
- Add a tiny dab of dielectric grease inside the boot.
- Push firmly until you feel or hear a subtle click.
That click is the sound of proper electrical commitment.
Make sure the lead is straight and not under tension.
Is This Motorcycle Different Than Any Other?
Not really.
The VS800 is a carbureted V-twin. Two cylinders. Two plugs. Straightforward.
What makes it “different” is the accessibility. Cruisers sometimes require a bit of patience because of tank shape and frame layout.
Mechanically though? Spark plugs are spark plugs.
Thread. Seat. Crush. Connect. Done.
How Often Should I Change Them?
For standard copper plugs like these:
- Every 8,000–10,000 miles is reasonable.
- Or sooner if you notice rough idle, hard starting, or reduced fuel efficiency.
They are cheap. Engines are not.
Any Other Interesting Tidbits?
Your old plugs are storytellers.
Light tan or gray deposits? Healthy mixture. Black and sooty? Running rich. White and blistered? Too lean or overheating.
Spark plugs are tiny combustion historians.
Also: always start threading by hand. I am repeating that because stripped aluminum heads are not funny.
Well, they are funny. But only to someone else.
Final Thoughts
Changing spark plugs on your 2005 Suzuki VS800 Boulevard S50 is one of those jobs that builds confidence.
It is simple. It is mechanical. It connects you to the machine.
And when it fires up cleanly after the swap?
That first smooth idle feels like a standing ovation from 805cc of appreciation.
If this helped, follow me for more hands-on motorcycle adventures and mildly questionable mechanical humor.
Drop a comment and tell me: Was your right plug also absurdly tight, or was that just my bike trying to test my character?
